DS-2CD6445G2-C1/HDMI Hikvision Box IP Camera
Product Overview
The Hikvision DS-2CD6445G2-C1/HDMI is a high-quality 4MP class IP network camera designed for reliable surveillance with advanced imaging and efficient compression. It uses a 1/2.7″ progressive scan CMOS sensor and supports a maximum resolution of 2688 × 1520. For low-light performance, it is rated at 0.005 lux in color mode (F1.2, AGC ON).
For video delivery, the camera supports multiple streams for flexible recording and monitoring. It can output up to 25 fps at 50 Hz and up to 30 fps at 60 Hz on the main stream, with support for H.265/H.264 compression. H.265+ is also highlighted for saving bandwidth and storage. Advanced image processing includes 3D DNR for cleaner and sharper images and digital WDR (wide dynamic range). Enhancement features include BLC and HLC, plus defog for improved clarity in challenging conditions.
The unit provides a standard HDMI video output, along with audio and alarm I/O for integration into larger systems. Network capabilities include support for common protocols such as RTSP/HTTP/HTTPS, secure transport options, and compatibility with Hikvision clients like iVMS-4200 and Hik-Connect. The camera also features onboard microSD storage support (up to 256 GB) and a built-in memory card slot.
With HEOP support, it supports embedded/open platform functionality and allows importing third-party applications. A deep learning structure is included (Caffe, PyTorch, TensorFlow) and face capture support is listed as a deep learning function.
Key Features
- HEOP (Hikvision Embedded Open Platform) support for importing third-party applications
- 4 TOPS computing power with 60 MB memory, 375 MB smart RAM, and 2 GB eMMC for sharing resources
- 4MP imaging (max. 2688 × 1520)
- Efficient H.265+/H.265 compression for reduced bandwidth and storage
- 1 standard HDMI video output
- Audio I/O: 1 line-in and 1 line-out (mono sound)
- Alarm I/O: 2 inputs and 1 output (max. 12 VDC, 30 mA)
- 3D DNR for clean and sharp images
- Digital WDR, plus BLC/HLC/Defog image enhancement
- Built-in microSD card slot supporting up to 256 GB
- Multiple streams with ROI (4 fixed regions per stream) and target cropping
- Smart events include line crossing, intrusion, and region entrance/exiting detection (with human/vehicle trigger support)
Watch Product Videos
Watch real demos, setup guides, night-vision tests, and feature highlights for this model.
We’re doing our best to find this video and add it here. Until then, click below and see if you can find it before we do.
Search nowWhere to Find This Product
View trusted supplier listings, product references, and availability status for this model.
Frequently Asked Questions
The maximum resolution is 2688 × 1520.
Yes. Main stream supports H.265/H.264, and the product highlights H.265+ for saving bandwidth and storage.
Yes. It has 1 standard HDMI video output.
Audio: 1 input (line in) and 1 output (line out). Alarm: 2 input(s) and 1 output (max. 12 VDC, 30 mA).
It has a built-in memory card slot that supports microSD/microSDHC/microSDXC cards up to 256 GB.
It lists line crossing detection, intrusion detection, region entrance detection, and region exiting detection, with alarm triggers for specified target types (human and vehicle).
