DS-2CD6944G1-IHS(U)Y Hikvision Fisheye IP Camera
Product Overview
The Hikvision DS-2CD6944G1-IHS(U)Y is a 16MP 180° panoramic network (IP) camera designed for wide-area monitoring with detailed clarity. It delivers a stitched panoramic view that covers the full field of view presented by the camera, making it suitable for video wall applications and broad scene surveillance.
For flexible remote positioning, the camera supports motorized pan and tilt angle adjustment. Imaging performance is supported by a 1/1.8″ progressive scan CMOS sensor, up to 4800 × 2688 maximum resolution, and color capture performance in low light environments with Hikvision DarkFighter technology. An integrated IR illuminator with 850 nm wavelength provides supplementary illumination up to 20 m.
Built for demanding outdoor installations, the unit includes a built-in heater and supports ultra-low temperature startup down to -40 °C (-40 °F). The camera is rated IP67 for water and dust resistance and IK10 for vandal resistance, making it appropriate for public-facing and harsh environments. Additional features listed in the datasheet include digital WDR, day/night switching modes, privacy masking, audio support, audio I/O, alarm I/O, and event-based actions such as motion detection and perimeter protection (line crossing, intrusion, region entrance/exit).
Key Features
- 180° splicing panoramic image for full wide-area view
- High resolution 16MP (max. 4800 × 2688)
- Remote motorized pan (0° to 340°) and tilt (0° to 90°) adjustment
- Built-in heater with ultra-low temperature startup down to -40 °C (-40 °F)
- DarkFighter technology for high-quality color images in dim light
- IR supplement light with 850 nm wavelength, range up to 20 m
- IP67 water/dust resistant and IK10 vandal proof
- H.265+/H.265/H.264+/H.264 video compression and SVC support
- On-board storage support via microSD/microSDXC up to 1024 GB
- Audio input/output support (line in/line out), built-in dual microphones
- Perimeter protection: line crossing, intrusion, region entrance, region exiting (human and vehicle support)
- People density support (only in panorama mode)
Watch Product Videos
Watch real demos, setup guides, night-vision tests, and feature highlights for this model.
We’re doing our best to find this video and add it here. Until then, click below and see if you can find it before we do.
Search nowWhere to Find This Product
View trusted supplier listings, product references, and availability status for this model.
Frequently Asked Questions
The maximum resolution is 4800 × 2688.
Yes. It supports 180° splicing image for a full panoramic view covered by the camera.
Pan is 0° to 340° and tilt is 0° to 90°.
The IR supplement light range is up to 20 m.
It is rated IP67 (water/dust resistant) and IK10 (vandal proof).
Yes. The camera includes a built-in heater and supports ultra-low temperature start up to -40 °C (-40 °F).
