DS-2DV6C425MXG-ELWY Hikvision PTZ Dome IP Camera
Product Overview
The Hikvision DS-2DV6C425MXG-ELWY is a vibration resistant 4MP network PTZ speed dome designed for long-range monitoring over expansive outdoor areas. It features a 1/1.8-inch progressive scan CMOS sensor and delivers up to 2688 × 1520 maximum resolution. A 25× optical zoom lens with 16× digital zoom enables detailed views across wide scenes, making it suitable for rivers, forests, roads, railways, airports, ports, squares, parks, scenic spots, stations and large venues.
For challenging low-light conditions, the camera uses DarkFighter 2.0 technology for improved sensitivity and provides an expansive night view with up to 200 m IR illumination distance and up to 50 m white light distance. The dome also supports low-latency decoding with a delay as low as 100 ms, helping reduce control lag. For stable imaging during movement, it includes a built-in gyroscope and supports Smart Pan-Tilt Correction.
PTZ performance includes 360° pan rotation and tilt from -20° to 90° (auto flip), with configurable pan/tilt speeds and 300 presets. The camera supports patrol scans, 3D positioning, scheduled tasks, and power-off memory. It is water and dust resistant with an IP67 rating and anti-corrosion protection rated as NEMA 4X, making it appropriate for harsh environments.
The DS-2DV6C425MXG-ELWY supports multiple video streams, H.265+/H.265/H.264 compression, and rich network and security features including TLS 1.3 and TPM 2.0 (FIPS 140-2 level 2).
Key Features
- 1/1.8″ progressive scan CMOS sensor
- 4MP max resolution (2688 × 1520)
- 25× optical zoom and 16× digital zoom
- DarkFighter 2.0 low-light performance
- Up to 200 m IR distance and up to 50 m white light distance
- Low latency decoding with delay as low as 100 ms
- Smart Pan-Tilt Correction
- Built-in gyroscope for stable image output
- PTZ: 360° pan, -20° to 90° tilt (auto flip)
- Up to 300 presets; 8 patrols with up to 32 presets per patrol
- 3D positioning, preset freezing, PTZ status display
- Scheduled tasks: preset/patrol scan/dome reboot/dome adjust/aux output
- Water/dust resistant IP67
- Power options: 36 VDC ±25% (max 60 W) and PoE 802.3bt type 4 class 7 (max 60 W)
Watch Product Videos
Watch real demos, setup guides, night-vision tests, and feature highlights for this model.
We’re doing our best to find this video and add it here. Until then, click below and see if you can find it before we do.
Search nowWhere to Find This Product
View trusted supplier listings, product references, and availability status for this model.
Frequently Asked Questions
It supports up to 2688 × 1520 (4MP).
It has 25× optical zoom and 16× digital zoom.
DarkFighter 2.0 technology.
IR distance up to 200 m and white light distance up to 50 m.
Pan is 360° and tilt is -20° to 90° (auto flip).
Yes. It is rated IP67 for water and dust resistance.
