DS-2XV6345G0-LHRSY(316L) Hikvision Fisheye IP Camera
Product Overview
The Hikvision DS-2XV6345G0-LHRSY(316L) is a 4MP vibration resistant fisheye network camera designed for robust outdoor surveillance. It uses a 1/3″ progressive scan CMOS sensor with a maximum resolution of 2688 × 1520, delivering a full 180.0° horizontal field of view (180.0° diagonal, 95.9° vertical) with a fixed 1.8 mm lens. The camera supports wide-area monitoring with pan and tilt adjustment (pan -15° to 15°, tilt -30° to 180°) to help align the installation view.
Built for challenging environments, the camera features an IP68 water/dust resistant rating and top-level anti-corrosion protection (NEMA 4X / C5) with a 316L stainless steel enclosure. For visibility in low-light conditions, it offers a supplemental light range up to 15 m and supports day/night modes (Day/Night/Auto/Schedule), with 120 dB WDR and SNR ≥ 50 dB for improved image clarity.
Connectivity and deployment are simplified with support for PoE (IEEE 802.3af, Class 3) and 9 to 36 VDC power input. Video is compressed with H.265/H.264 (plus H.265+/H.264+) and includes multiple streams for flexible recording and viewing. Smart detection features include perimeter protection such as line crossing, intrusion, and region entrance/exiting, with alarm triggering by specified target types (human and vehicle). A built-in wiper with a G1/8 water pipe connector helps maintain a clear view in adverse weather.
Key Features
- 4 MP max resolution (2688 × 1520) with 1/3″ progressive scan CMOS sensor
- 180° horizontal fisheye field of view (1.8 mm fixed focal lens)
- Vibration resistant design (as stated in product name)
- Water and dust resistant rating: IP68
- 316L stainless steel material
- Top-level anti-corrosion protection (NEMA 4X / C5)
- PoE support (IEEE 802.3af, Class 3) and 9 to 36 VDC power input
- Built-in wiper and G1/8 water pipe connector
- Supplement light range up to 15 m
- Day/Night/Auto/Schedule switching
- Wide Dynamic Range (WDR) 120 dB and SNR ≥ 50 dB
- Video compression: H.265/H.264 (with H.265+/H.264+ support for main stream)
- Smart perimeter protection: line crossing, intrusion, region entrance, region exiting (human/vehicle trigger support)
- Built-in scheduling and linkage options (FTP/NAS upload, email, trigger recording/capture)
Watch Product Videos
Watch real demos, setup guides, night-vision tests, and feature highlights for this model.
We’re doing our best to find this video and add it here. Until then, click below and see if you can find it before we do.
Search nowWhere to Find This Product
View trusted supplier listings, product references, and availability status for this model.
Frequently Asked Questions
It supports a maximum resolution of 2688 × 1520 (4 MP).
With the 1.8 mm fixed focal lens, it offers 180.0° horizontal FOV (180.0° diagonal, 95.9° vertical).
Yes. It is IP68 water and dust resistant and uses a 316L stainless steel enclosure with top-level anti-corrosion protection.
Yes. It supports PoE (IEEE 802.3af, Class 3) with max power specified for PoE operation.
The supplement light range is up to 15 m, and the camera supports Day/Night/Auto/Schedule modes.
Yes. It supports line crossing, intrusion, and region entrance/region exiting, including alarm triggering by specified target types (human and vehicle).
